Infortrend storage systems now come with super-speed host interface support for 56 Gb/s InfiniBand, 40 Gb/s iSCSI, and 4 x 16 Gb/s Fibre Channel ports to deliver optimum bandwidth and throughput for resource intensive and mission critical applications such as high-performance computing, media editing, and big data analytics.
Featuring high bandwidth for high throughput and low latency, InfiniBand is a networking communications standard used in high-performance computing (HPC) such as data centers and big data applications. It is utilized as a data interconnect within computers, a direct or switched interconnect between servers and storage, as well as an interconnect between storage systems.
InfiniBand is increasingly used in data centers and HPC as it drives the most aggressive performance roadmap among I/O fabric infrastructures. iSCSI targets enterprise data center, cloud and big data applications requiring high-performance SAN-based storage. FC ports enable high throughput to support the most demanding virtualization applications.
Infortrend storage systems now provide flexible super-speed host interface support for 56Gb/s InfiniBand, 40Gb/s iSCSI and 4 x 16Gb/s Fibre Channel ports to meet the bandwidth and throughput requirements by resource intensive and mission critical applications.
56Gb/s InfiniBand Connectivity
Next generation I/O fabric architecture featuring the highest bandwidth and lowest latency targeting performance sensitive data centers and enterprise environments.
Applications
- High performance computing
- Digital media processing or streaming
- Clustered databases
- Online transaction processing
* InfiniBand channel ports support the SRP protocol and Linux hosts.
40Gb/s iSCSI Connectivity
A higher bandwidth, lower latency and more scalable SAN solution beyond the SMB space, taking advantage of Ethernet for simple and cost-saving enterprise data center deployment.
Applications
- Cloud services
- Big data analytics
16Gb/s Fibre Channel Connectivity
4 x 16Gb/s FC ports delivering a high 64G throughput supporting the most demanding applications when leveraging multicore processors, memory cache and SSD.
Applications
- Virtualization
- Virtual Desktop Infrastructure
Widest Host Interface Options
Infortrend storage systems provide comprehensive and flexible host interface options through an interchangeable modular-design host board:
- 56Gb/s InfiniBand
- 40Gb/s or 10Gb/s iSCSI
- 16Gb/s or 8Gb/s FC
- 10Gb/s FCoE
- 12Gb/s SAS
EonStor DS 4000U models support InfiniBand, providing users with more options while offering the same excellent performance you’ve come to expect from Infortrend. Thanks to optimized design and advanced processing power, EonStor DS 4000U can deliver up to 1.5M IOPS, 11,000MB/s read and 5,500 write.
Models supporting super-speed host interfaces:
For more information about interchangeable host connectivity for Infortrend storage systems contact
